Wind Direction Sensor (BS110-02)

Introduction to Sensor

Wind Direction Sensor (BS110-02)

Measures Wind Direction,
Detects Wind Origin Angle,
Tracks Wind Source

The BS110-02 is a high-performance Wind Direction Sensor engineered for accurate and real-time monitoring of wind direction in diverse environments. Utilizing high-precision magnetic-sensitive chips embedded within a durable housing, it ensures reliable operation under varying weather conditions. The wind vane, made from lightweight, low-inertia metal, is designed to respond swiftly and accurately to even minor wind direction changes.

Whether deployed in stationary stations or mobile platforms, the BS110-02 provides consistent, precise wind direction data, making it a reliable choice for both commercial and industrial meteorological applications.

Specifications

Specifications

Output

4 ~ 20mA

0 ~ 5V

RS485

Supply Voltage

5V, 12V ~ 24V

5V, 12V, 24V

5V, 12V ~ 24V

Load Capacity

<500Ω (typ 250Ω)

>1kΩ



Range

0 ~ 360°

Accuracy

±3°

Resolution

Starting Threshold

<0.5m/s

Limit Wind Speed

50m/s

Ingress Protection

IP65

Operating Temperature

-40°C ~ 50°C

Cable Grade

Nominal Voltage: 300V, Temperature Grade: 80°C

Weight (Unpacked)

165g

Dimension

Turning Radius: 147mm, Height: 166mm

Main Material

Carbon Fiber

Storage Condition

10°C ~ 50°C @ 20% ~ 60%RH

Features

Special Features

01

Low Starting Threshold

Accurately detects wind speed even at very low air movement.
02

Strong Corrosion Resistant Ability

Designed to perform reliably in harsh outdoor environments.
03

Great Dynamic Characteristics

Ensures fast, precise response and performance under changing conditions.
04

Overall Carbon Fiber Material

Provides high-strength, lightweight construction for durability and easy handling.
05

Easy Installation

Easy installation with standard poles and common sensors.
06

Light Structure

Offers a lightweight design for easy installation and reduced load.
07

Multiple Outputs

Supports multiple signal output options for flexible system integration.
08

High Accuracy

Delivers stable, precise, and highly reliable wind speed measurements.
Applications

Primary Applications

Weather Monitoring Stations
Remote Airports and Helipads
Solar and Wind Power Generation
Mobile Weather Monitoring Vehicles
