Buraq Integrated Solutions provides advanced data-acquisition (DAQ) systems designed for precise and reliable structural health monitoring. Our platforms are ideal for applications ranging from simple beam-fatigue studies to long-term monitoring of large and complex structures. They support a wide range of sensors including strain gauges, accelerometers, displacement sensors (LVDT, VW, potentiometric), tiltmeters, and temperature sensors.
Our GRANITE™ modular system adapts easily to projects of any size. Each module can operate independently with direct PC connection or integrate into a synchronized multi-module DAQ network.
The modular design allows simple expansion, support for multiple sensor types, and closer sensor placement for higher accuracy. When connected to the central GRANITE™ DAQ, all modules operate in precise time alignment for a flexible and scalable monitoring solution.
Data retrieval is seamless and versatile, supporting multiple interfaces including direct PC connection, microSD storage, Ethernet, Wi-Fi, and other wireless communication technologies. This ensures dependable data access whether you are on-site or working remotely.
Our PC-based software provides real-time monitoring, automated data scheduling, device configuration, and instant visualization of measurements. Integrated error-checking routines maintain data reliability, while remote access capabilities allow users to manage and review system performance from anywhere. For wider accessibility, we also offer secure web publishing options, enabling stakeholders to view live or historical data through online dashboards.
Multiple GRANITE™ modules can be placed throughout a structure and linked back to a central DAQ, significantly reducing cable lengths, installation costs, and signal noise.
The system ensures exceptional timing accuracy through:
Built-in GPS with 1 µs pulse-per-second accuracy
Clock synchronization within 200 ns of GPS
High-precision, temperature-compensated internal clock with ±3 min/year accuracy
CPI synchronization: ±5 µs across modules (up to 2,000 ft)
EPI synchronization: ±50 ns across modules (up to 300 ft per segment)
SPECTRUM modules: calibrated to achieve ±10 ns channel-to-channel precision
These capabilities make GRANITE™ ideal for highly time-sensitive and large-scale structural monitoring.
Our DAQs work with nearly all commercial structural and seismic sensors, including:
Vibrating-wire & foil strain gauges
Carlson strain meters
Inclinometers
Crack/joint sensors
Tilt sensors
Piezoresistive, piezoelectric, capacitive & servo accelerometers
Borehole accelerometers
