The Air Quality Wind-Speed and Wind-Direction Sensor is an excellent choice for precise air-quality and meteorological monitoring. Engineered to be lightweight, accurate, and high-performance, this sensor delivers superior responsiveness and reliability compared to conventional wind monitors. Its low starting threshold, rapid response, and enhanced measurement accuracy make it ideal for demanding environmental applications.
Constructed from rigid, UV-stabilized thermoplastic with stainless-steel and anodized-aluminum fittings, the sensor offers exceptional durability and resistance to corrosion caused by sea-air environments and atmospheric pollutants. Precision-grade stainless-steel ball bearings on both the propeller and vertical shafts ensure long-term stability and measurement integrity.
Overall, this wind monitor is a robust and dependable solution for professionals seeking high-quality wind measurement in air-quality monitoring systems.
Buraq is the top renewable
energy solutions in the World
| Applications |
|
| Sensor | Helicoid-shaped, 4-blade propeller and fuselage-shaped sensor body |
| Measurement description | Wind speed and direction |
| Operating temperature range | -50° to +50°C (assuming non-riming conditions) |
| Mounting pipe description | 34 mm (1.34 in.) OD Standard 1.0-in. IPS schedule 40 |
| Housing diameter | 5 cm (2.0 in.) |
| Height | 38 cm (15.0 in.) |
| Length | 65 cm (25.6 in.) |
| Propeller diameter | 20 cm (7.9 in.) |
| Weight | 1.1 kg (2.5 lb.) |
Fully compatible with most Buraq Integrated Solutions data loggers.
Built with thermoplastic materials that resist corrosion in harsh marine and polluted environments.
Provides a lower starting threshold, faster response, and higher accuracy than typical wind monitors.
- Compatible with the LLAC4 4-Channel Low-Level AC-Conversion Module, enabling more anemometers to be measured by a single data logger.
Works with the CWS900-series interfaces, supporting integration into wireless sensor networks.
05103 – Standard version
05103-45 – Rugged alpine model for extreme cold environments
05305 – Highly responsive model (less rugged)
05106 – Marine-grade version for harsh coastal conditions
